Servo Press and pressing process monitoring

Auloma Holding S.r.l.

Original Italian producers of servo presses with pressing monitoring for industrial processes

Auloma is the main Italian manufacturer of servo press with pressing monitoring integrated for assembling press fit, metal forming and others industrial applications. In our range of products you can find servo presses for micro mechanic application until presses for heavy duties of 300 kN. All our devices could be equipped with our process monitoring system to analyse in run industrial processes such us : press fit, joining and crimping and more. Auloma devices can satisfy the exigences of many machine integrator and many industries. The high quality of our Servo Press Modules depend by many elements such as top level of components used, a robust and stiffness structure, an accurate force quality control, obtained by the use of precise force sensors. Skills and Knowledge makes Auloma Holding S.r.l a partner capable to offer advanced solutions in process monitoring devices applicable in many industrial fields to obtain a production with zero defects. All our devices are developed to provide the right benchmark to enhance your Six Sigma curve and to respect the ISO TS 16949. This is the new frontiers of industrial automation....

For more see our company activity ❱


Servo press IOT compliant

Internet of things applied at the pressing process

servo press iot compliant
Servo press compliant for Internet Of Things

Since 2010 Auloma produces servo presses IoT compliant. Our software APM-BA throug the Ethernet socket provide the analysis of the pressing process to whichever PC connected and the raw data in CSV format can be managed easily by your or our SPC (Statistical Process Control). The open achitecture of our system allow you to apply a real software costs management, the pressing process analysis data in CSV format doesn't need of dedicated and expensive software for statistical analysis, the use of free software, software in cloud or simple spreadsheet it is possible. Discover how our servo press IoT compliant, can reduce your costs and how improve the quality of your products with an analysis of tour pressing process in real time.

For more see our servo press range ❱


Servo Press Machine For Valve Seat

valve seat machine
Servo press for valve seat

Auloma Holding S.r.l. has developed a servo press dedicated for the seat and valve guide insertion. The servo press are developed for Bajaj Auto the main motorbike producers in the world.“Bajaj has find in Auloma, further a partner capable to develop a project tailor made, a source of knowledge in engine assembling by automated process“ said Auloma Founder and CEO Lazzaro Marsilla. The servo presses developed for Bajaj are used for the insertion of the valve guide and the valve seat in the single cylinder engine. “Also in this project Auloma has demonstrated his capability of problem solving. One of the main Bajaj inquiry was an extreme alignment of the servo press ram with the bored holes in the head's engine. The servo press developed can guarantee a perfect alignment thanks to the reduced backlash between the ram guide and the preloaded anti-twist ram.“ Said Mr. Marsilla.The restrictive tolerance used to fit the valve seat has required a very stiffness ram spindle. To enhance the ram position under the compressive strength, all components was be verified by FEM. To be more precise in ram positioning, Auloma has eliminated any influence procured by the force sensor deflection. Thanks to the FEM .....

For more see Bajaj case history ❱


Servo Press P5124

servo press

In many application, control Force and Displacement has a direct impact on product quality. When press fit a seat valve in an engine head, for example, insertion force and displacement must be controlled very precisely. The first step to have a superlative servo press control consist in a stiffness servo press. The heart of Auloma's P5 servo press is the preloaded ball screw with an high dynamic load capability. Have a stiffness press means a precise force measurement without dispersion for weakness. More your press will be stiffness, more the Force sensor will be capable to measure a small force variation. The ball screw preloaded give at our P5 servo presses another advantage, the nut hasn't any axial backlash and allow precise ram position. Our P5 servo presses can provide ram's precise absolute position and not only a value of repeatability as many our competitors........

For more see our P5 Servo Presses ❱


Servo tandem pneumatic cylinder IOT

Internet of things now available also in tandem pneumatic cylinder

tandem pneumatic cylinder iot compliant
Tandem pneumatic cylinder compliant for Internet of Things

Auloma thanks to its skills in pressing process monitoring has developed a system capable to transform a simple pneumatic tamdem cylinder, in a new intelligent device IoT compliant. Often many pressing operations don't need of expensive servo presses but is enough a tandem pneumatic cylinder. Auloma's pneumatic cylinder provide a constant force for the entire stroke and can provide until 50kN in compression and a low consumption of air in returning stroke. The device has intalled sensors capable of monitoring the compressive force during the stroke. A simplyfied APM process monitoring devoleped for the scope gathering and analyse the data of the cylinder and through the Eternet socket this data can be download to all PC machine in your network. To know more about our IoT pneumatic cylinder visit:

Tandem pneumatic cylinder overview ❱


Servo Press

Video: Servo Press Applications

Press fit applications and metal forming.
